Rally Bar

SIMPLE AND FLEXIBLE VIDEO CONFERENCING FOR ANY ROOM
With flexible deployment, easy setup, integration with leading video conferencing platforms, and remote management, the Logitech Rally series enables organizations to deliver seamless communication and empower collaboration for the modern hybrid workforce.

SIMPLE DEPLOYMENT
Designed to make video meetings effortless, the Rally series offers fast setup, easy management, and seamless integration with meeting room controllers like Tap IP.

BETTER TOGETHER WITH LOGITECH SOLUTIONS
Simplify setup, joining, and management of video meetings with integrated solutions that pair select conference cameras with Tap IP – a network-connected touch controller. With one-touch join, wireless content sharing, simplified cabling, and central room control, video conferencing has never been easier.

Rally Bar + Tap IP: A complete solution featuring an all-in-one video bar and a touch controller with PoE connectivity. Ideal for medium to large rooms of up to 20 participants. For larger rooms, deploy additional Rally Mic Pods to expand the beamforming microphone array across the entire space.

SEE EVERYONE CLEARLY
Built-in AI-powered smart video capabilities ensure that all meeting participants are clearly visible, delivering a better experience for remote attendees. Plus, watch your devices get even smarter over time with regular updates that add advanced features, enhance compatibility, and unlock deeper integration with Logitech platforms and other products.

HEAR EVERYONE CLEARLY
Ensure that remote participants can hear everyone in the room clearly so they feel fully engaged in the discussion. Rally conference cameras and video bars feature powerful, clear audio pickup optimized by AI noise suppression, RightSound™, and support for up to 7 additional Mic Pods¹. The number of available Mic Pods may vary depending on the camera model. Together, these capabilities create a more natural and immersive meeting experience for remote workers.

EASY TO MANAGE
Easily manage all your spaces—from meeting rooms to personal workstations—at scale with Logitech Sync, the device and space management platform designed to support the hybrid workforce. Monitor room status, deploy updates, and adjust settings—all from a single, cloud-based platform. And with Sync Insights, you can understand how meeting spaces are being used over time.

Thông số kỹ thuật

General Specifications

Integrated Components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management and retention system, table mount, Logitech CollabOS platform
Enclosure: All-in-one design with built-in table mount and patented speaker suspension system to eliminate camera shake from vibration and audio interference
Device Management: Logitech Sync
Supported Displays: 2
Display Resolution: Up to 1080p
Network Protocol Support: IPv4, IPv6
Proxy Support: IP-based proxy, FQDN-based proxy, PAC file proxy

Camera

Resolutions: 4K, 1440p, 1080p, 900p, 720p, and SD at 30 fps
Pan (Motorized): ±25°
Tilt (Motorized): ±15°
Zoom: 15x HD (5x optical, 3x digital)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage (FOV + pan/tilt): Horizontal 132.1° × Vertical 82.2°

Speakers

Driver Size: 2 × 70 mm
Sensitivity:
- 92 dB SPL @ 1W
- 99 dB SPL @ 8W
- Both ±2 dB @ 0.5 m
Rated Output Power: 8W
THD: <2% at 1W @ 1kHz
Speaker Sampling Rate: 48 kHz
Impedance: 4 ohms

Microphones

Frequency Response: 90Hz – 16kHz
Sensitivity: >-36 dBFS ±1 dB @ 1 Pa
Microphone Data Rate: 48 kHz
Pickup Range: Up to 7 m
Beamforming Elements: 6 omnidirectional digital MEMS microphones forming 5 adaptive horizontal beams
Audio Processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detection)
Noise Suppression: AI-based noise reduction algorithm
Mic Expansion: Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms

Operating Environment

Operating Temperature: 0 to 40°C
Storage Temperature: -40 to 70°C
Humidity: 10 to 95%
BTU/hr: 57 (idle), 64 (in meeting)

Security

Full Disk Encryption: USB port available
Data Encryption: Symmetric keys, PKI
Device Identity: Protected by device attestation
Device Access: Authenticated via API
Secure Enclave: Arm TrustZone, RPMP

Accessories

Mounting: Video Bar Wall Mount, Video Bar TV Mount
Audio: Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable
Connectivity: Logitech robust USB cables (10m, 25m, 45m)
Touch Controllers: Logitech Tap and Tap IP³
Compatibility may vary; see www.logitech.com/support/tap-compatibility for the latest info

Warranty

Standard: Includes 2-year limited hardware warranty
Extension: Optional 1-year and 3-year warranty extensions available at hardware purchase. Contact your reseller for availability
